SmartLase F500

Specifications

PRODUCT CODE SmartLase F500

PRINTHEAD ...

CONTROLLER ...

TEMPERATURE RANGE ...

VOLTAGE ...

DUST/MOISTURE PROTECTION ...

The F500 is designed to suit the beverage industry, specifically for high-speed can production lines with speeds up to 1750 cans/minute. The F500 fiber laser printer uses a touchscreen for easy operation and simple news updates. The industrial design with IP55 protection and the ability to operate up to 100,000 hours.

Substrate Materials

• Metal
• Rubber
• Glass bottles/jars
• Flexible tubes
• Electrical equipment

• Plastic crates/boxes
• Cardboard boxes
• Decorative labels
• Packaging
• Corrugated materials

• Lids
• Cans
• Cables
• Light bulbs
• ...

Application Areas

• Food industry
• Beverages
• Pharmaceuticals

• Cosmetics
• Component manufacturing
• Electrical/electronics

• Automotive
• Aerospace
• ...

Technology

LASER PRINTING

Speed

MEDIUM SLOW

Description
Specifications

Technical Specifications

• Machine size: WxLxH
• Controller: 697x210x700
• Laser head: 110x490x124
• Printing area: 55×55-242x242mm
• Laser source life: 100,000h
• Character engraving speed: 2.400 characters/s
• Printing speed: 120-640m/min
• 1750 cans/minute
• Laser power: 50W
